Category

Analog layout design rules
Matching transistor layouts is crucial for minimizing electrical variations, especially in analog and mixed-signal circuits like differential amplifiers. Proper design ensures symmetry, precision, and low...
How to design an Operational Transconductance Amplifier (OTA)?
This article explains how to design an Operational Transconductance Amplifier (OTA) in Cadence, focusing on optimizing transistor dimensions. It covers hand calculations and the gm/ID...
Introduction to capacitors
This tutorial introduces the basics of capacitors, covering their structure, energy storage, and behavior in DC and AC circuits. It explains capacitance, charging/discharging processes, and...
Essential tools for electronic hobbyist (2024)
Lab equipment is essential for home electronics projects. Key tools include a multimeter, soldering station, oscilloscope, and power supply. This guide covers affordable options for...
Resistor color code – Online tool
A resistor is a fundamental two-terminal component used in countless electronic devices to limit or regulate electric current. Resistors are often marked with color bands...
3-phase IGBT-inverter – Working principles
In this article the 3-phase IGBT inverter and its functional operation are discussed. In order to realize the 3-phase output from a circuit employing dc...

Prerequisits

To make it easier, I assume you have a basic knowledge of the following:

  • Basic circuitry knowledge; such as resistors, transistors, diodes, relays.
  • Basic programming knowledge in C; understand what are functions, operators, data types, and more.
  • Digital electronics, such as logic gates.

On some occasions I will explain it from scratch, but to understand everything, it is best to brush up on the basics so that you can follow the tutorials.

Required Software

For these tutorials we use Microchip’s own software package that includes:

  • MPLAB X IDE
  • XC8 Compiler
  • PICKIT3 programmer/debugger

All the tools can be downloaded at the official website of Microchip Technology

Required Hardware

The full tutorial consists of many different types of electrical components, sensors and actuators. It depends completely on your own project what you need. However, in all cases you will need a Pickit3 tool to install the software and you need at least 1 PIC16F877A microcontroller to install it on.
